Advance Encryption Standard Accelerator (AES)
17.4.39 DTHE_AES_RIS Register (Offset = 824h) [reset = X]
DTHE_AES_RIS is shown in Figure 17-52 and described in Table 17-42.
Return to Summary Table.
AES Raw Interrupt status register.
Figure 17-52. DTHE_AES_RIS Register
31 30 29 28 27 26 25 24
RESERVED
R-X
23 22 21 20 19 18 17 16
RESERVED
R-X
15 14 13 12 11 10 9 8
RESERVED
R-X
7 6 5 4 3 2 1 0
RESERVED Dout Din Cout Cin
R-X R-0h R-0h R-0h R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 17-42. DTHE_AES_RIS Register Field Descriptions
Bit Field Type Reset Description
31-4 RESERVED R X
3 Dout R 0h
Output data movement is done
2 Din R 0h
Input data movement is done
1 Cout R 0h
Context output is done
0 Cin R 0h
Context input is done
