Power, Reset, and Clock Management
15.6.3 CAMSWRST Register (offset = 8h) [reset = 0h]
CAMSWRST is shown in Figure 15-6 and described in Table 15-6.
Figure 15-6. CAMSWRST Register
31 30 29 28 27 26 25 24
RESERVED
R-0h
23 22 21 20 19 18 17 16
RESERVED
R-0h
15 14 13 12 11 10 9 8
RESERVED
R-0h
7 6 5 4 3 2 1 0
RESERVED ENSTS SWRST
R-0h R-0h R/W-0h
Table 15-6. CAMSWRST Register Field Descriptions
Bit Field Type Reset Description
31-2 RESERVED R 0h
1 ENSTS R 0h
CAMERA_ENABLED_STATUS
0h = Camera clocks/resets are disabled
1h = Camera clocks/resets are enabled
0 SWRST R/W 0h
CAMERA_SOFT_RESET
0h = Deassert reset for Camera-core
1h = Assert reset for Camera-core
