Analog-to-Digital Converter (ADC)
13.4.1.7 ADC_CH2_IRQ_STATUS Register (offset = 4Ch) [reset = 0h]
ADC_CH2_IRQ_STATUS is shown in Figure 13-9 and described in Table 13-9.
Figure 13-9. ADC_CH2_IRQ_STATUS Register
31 30 29 28 27 26 25 24
RESERVED
R-0h
23 22 21 20 19 18 17 16
RESERVED
R-0h
15 14 13 12 11 10 9 8
RESERVED
R-0h
7 6 5 4 3 2 1 0
RESERVED ADC_CHANNEL2_IRQ_STATUS
R-0h R/W-0h
Table 13-9. ADC_CH2_IRQ_STATUS Register Field Descriptions
Bit Field Type Reset Description
31-4 RESERVED R 0h
3-0 ADC_CHANNEL2_IRQ_S
TATUS
R/W 0h
Interrupt status register for ADC channel. Interrupt status can be
cleared on write.
Bit 3: when value 1 is written -> Clears FIFO overflow interrupt status
in the next cycle. If the same interrupt is set in the same cycle, then
the interrupt would be set and the clear command ignored.
Bit 2: when value 1 is written -> Clears FIFO underflow interrupt
status in the next cycle.
Bit 1: when value 1 is written -> Clears FIFO empty interrupt status
in the next cycle.
Bit 0: when value 1 is written -> Clears FIFO full interrupt status in
the next cycle.
