13.4.1.19 ADC_CH4_FIFO_LVL Register (offset = A4h) [reset = 0h]
ADC_CH4_FIFO_LVL is shown in Figure 13-21 and described in Table 13-21.
Figure 13-21. ADC_CH4_FIFO_LVL Register
31 30 29 28 27 26 25 24
RESERVED
R-0h
23 22 21 20 19 18 17 16
RESERVED
R-0h
15 14 13 12 11 10 9 8
RESERVED
R-0h
7 6 5 4 3 2 1 0
RESERVED ADC_CHANNEL4_FIFO_LVL
R-0h R-0h
Table 13-21. ADC_CH4_FIFO_LVL Register Field Descriptions
Bit Field Type Reset Description
31-3 RESERVED R 0h
2-0 ADC_CHANNEL4_FIFO_
LVL
R 0h
This register shows the current FIFO level. FIFO is 4 words wide.
Possible supported levels are 0x0 to 0x4.
