Data Encryption Standard Accelerator (DES)
18.5.10 DES_KEY1_H Register (Offset = 1014h) [reset = 0h]
DES_KEY1_H is shown in Figure 18-17 and described in Table 18-17.
Return to Summary Table.
KEY1 (MSW) for 192-bit key.
Figure 18-17. DES_KEY1_H Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
KEY1_H
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 18-17. DES_KEY1_H Register Field Descriptions
Bit Field Type Reset Description
31-0 KEY1_H R/W 0h
Data for key1
