AES Registers www.ti.com
642
SWRU543–January 2019
Submit Documentation Feedback
Copyright © 2019, Texas Instruments Incorporated
Advance Encryption Standard Accelerator (AES)
17.4.19 AES_IV_IN_2 Register (Offset = 48h) [reset = 0h]
AES_IV_IN_2 is shown in Figure 17-32 and described in Table 17-22.
Return to Summary Table.
Initialization vector input
Figure 17-32. AES_IV_IN_2 Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
DATA
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 17-22. AES_IV_IN_2 Register Field Descriptions
Bit Field Type Reset Description
31-0 DATA R/W 0h
IV data
17.4.20 AES_IV_IN_3 Register (Offset = 4Ch) [reset = 0h]
AES_IV_IN_3 is shown in Figure 17-33 and described in Table 17-23.
Return to Summary Table.
Initialization vector input (MSW)
Figure 17-33. AES_IV_IN_3 Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
DATA
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 17-23. AES_IV_IN_3 Register Field Descriptions
Bit Field Type Reset Description
31-0 DATA R/W 0h
IV data
