6 Input/Output

6.1 RF Source

Command

| M1 | M2 | M3 | M4 | M1M2 | M1M3 | M1M4 | M2M3 | M2M4 | M3M4 | M1M2M3 |

M1M2M4 | M1M3M4 | M2M3M4 | M1M2M3M4 | ALL, \{<waveform2>, <reps>, NONE | M1 |

M2 | M3 | M4 | M1M2 | M1M3 | M1M4 | M2M3 | M2M4 | M3M4 | M1M2M3 | M1M2M4 |

M1M3M4 | M2M3M4 | M1M2M3M4 | ALL,\} …

For additional description of each item, see "For Setup SCPI" on page 2006 below

:SOURce:RADio:ARB:SEQuence[:MWAVeform]? <filename>

For additional description of each item, see "For Query SCPI" on page 2007 below

Example For setup:

:SOUR:RAD:ARB:SEQ "NVWFM:testSeq1.seq", "NVWFM:wfmSegment1.wfm",10, M2M3M4,

"NVWFM:wfmSegment2.wfm", 20, M1M3

:SOUR:RAD:ARB:SEQ "D:\NVARB\testSeq1.seq", "D:\NVARB\wfmSegment1.wfm",10,

M2M3M4, "D:\NVARB\wfmSegment2.wfm", 20, M1M3

For query, must specify which waveform sequence file to query

:SOUR:RAD:ARB:SEQ? "NVWFM:testSeq1.seq"

:SOUR:RAD:ARB:SEQ? "D:\NVARB\testSeq1.seq"

For Setup SCPI

For the Setup SCPI command, the parameters are:

<filename> - String Type

This variable specifies the path and name for the waveform sequence file. The path

supports MSUS (NVWFM) or a real full path representation. See example.

<waveform1> - String Type

This variable specifies the path and name of the first existing waveform segment.

The path supports MSUS (NVWFM) or a real full path representation. See example.

The segment file must reside within ARB playback memory before it can be played

by the ARB player.

<reps> - Integer Type

This variable specifies the number of times a segment or sequence plays before

moving on to the next segment or sequence.

<marker> - Enum Type

NONE – This choice disables all four markers for the waveform. Disabling markers

means that the waveform sequence ignores the segments or sequence marker

settings.

M1, M2, M3, M4 – these choices, either individually or a combination of them,

enable the markers for the waveform segment or sequence. Markers not specified

are ignored for that segment or sequence.

Short Range Comms & IoT Mode User's &Programmer's Reference 2006
