RX23W Group 23. Multi-Function Timer Pulse Unit 2 (MTU2a)
x: Don't care
Note 1. When the MTU4.TMDR.BFB bit is set to 1 and the MTU4.TGRD register is used as a buffer register, this setting is invalid and
input capture/output compare is not generated.
x: Don't care
Note 1. When PCLK/1 is selected as the count clock for MTU1, MTU0 input capture is not generated. Do not select PCLK/1 as the count
clock for MTU1.
Table 23.17 TIORL (MTU4)
Bit 7 Bit 6 Bit 5 Bit 4 Description
IOD[3] IOD[2] IOD[1] IOD[0] MTU4.TGRD Function MTIOC4D Pin Function
0 0 0 0 Output compare register*
1
Output prohibited
0 0 0 1 Initial output is low.
Low output at compare match.
0 0 1 0 Initial output is low.
High output at compare match.
0 0 1 1 Initial output is low.
Toggle output at compare match.
0 1 0 0 Output prohibited
0 1 0 1 Initial output is high.
Low output at compare match.
0 1 1 0 Initial output is high.
High output at compare match.
0 1 1 1 Initial output is high.
Toggle output at compare match.
1 x 0 0 Input capture register*
1
Input capture at rising edge.
1 x 0 1 Input capture at falling edge.
1 x 1 x Input capture at both edges.
Table 23.18 TIORH (MTU0)
Bit 3 Bit 2 Bit 1 Bit 0 Description
IOA[3] IOA[2] IOA[1] IOA[0] MTU0.TGRA Function MTIOC0A Pin Function
0 0 0 0 Output compare register Output prohibited
0 0 0 1 Initial output is low.
Low output at compare match.
0 0 1 0 Initial output is low.
High output at compare match.
0 0 1 1 Initial output is low.
Toggle output at compare match.
0 1 0 0 Output prohibited
0 1 0 1 Initial output is high.
Low output at compare match.
0 1 1 0 Initial output is high.
High output at compare match.
0 1 1 1 Initial output is high.
Toggle output at compare match.
1 0 0 0 Input capture register Input capture at rising edge.
1 0 0 1 Input capture at falling edge.
1 0 1 x Input capture at both edges.
1 1 x x Capture input source is count clock in MTU1.
Input capture at MTU1.TCNT up-count/down-count.*
1
