R01UH0823EJ0100 Rev.1.00 Page 590 of 1823

Jul 31, 2019

RX23W Group 23. Multi-Function Timer Pulse Unit 2 (MTU2a)

(3) Input Capture Signal Timing

Figure 23.83 shows the input capture signal timing.

Figure 23.83 Input Capture Input Signal Timing

TCNT

Input capture input

TGR

Input capture signal

PCLK

NN + 1

N + 2
