RX23W Group 32. USB 2.0 Host/Function Module (USBc)

Figure 32.5 shows an example of host connection of the USB connector.

Figure 32.5 Sample Host Connection of USB Connector

External connection

MCU

Power

supply IC

for non-

OTG USB

host

VBUS

USB0_DP

USB0_DM

USB

A connector

D+

D–

VBUS

USB0_VBUSEN

USB

transceiver

USB0_OVRCURA

DRV

: Output impedance

: Pull-down resistor

At least 120 µF

Note 1. When Battery Charging Spec. Rev.1.2 is to be

supported, ensure that the power supply IC and the

VBUS wiring width are enough for at least 1.5 A.
