The SysTick counter reload and current value are undefined at reset; the correct initialization sequence for
the SysTick counter follows:
1. Program the value in the STRELOAD register.
2. Clear the STCURRENT register by writing any value to it.
3. Configure the STCTRL register for the required operation.
NOTE: When the processor is halted for debugging, the counter does not decrement.
3.2.2 Nested Vectored Interrupt Controller (NVIC)
This section describes the NVIC and the registers it uses. The NVIC supports:
• A programmable priority level of 0 to 7 for each interrupt. A higher level corresponds to a lower priority,
so level 0 is the highest interrupt priority.
• Low-latency exception and interrupt handling
• Level and pulse detection of interrupt signals
• Dynamic reprioritization of interrupts
• Grouping of priority values into group priority and subpriority fields
• Interrupt tail-chaining
• An external nonmaskable interrupt (NMI)
The processor automatically stacks its state on exception entry and unstacks this state on exception exit,
with no instruction overhead, providing low-latency exception handling.
3.2.2.1 Level-Sensitive and Pulse Interrupts
The processor supports both level-sensitive and pulse interrupts. Pulse interrupts are also described as
edge-triggered interrupts.
A level-sensitive interrupt is held asserted until the peripheral deasserts the interrupt signal. Typically, this
happens because the interrupt service routine (ISR) accesses the peripheral, causing it to clear the
interrupt request. A pulse interrupt is an interrupt signal sampled synchronously on the rising edge of the
processor clock. To ensure the NVIC detects the interrupt, the peripheral must assert the interrupt signal
for at least one clock cycle, during which the NVIC detects the pulse and latches the interrupt.
When the processor enters the ISR, it automatically removes the pending state from the interrupt (see
Section 3.2.2.2 for more information). For a level-sensitive interrupt, if the signal is not deasserted before
the processor returns from the ISR, the interrupt becomes pending again, and the processor must execute
its ISR again. As a result, the peripheral can hold the interrupt signal asserted until it no longer needs
servicing.
3.2.2.2 Hardware and Software Control of Interrupts
The Cortex
®
-M4 latches all interrupts. A peripheral interrupt becomes pending for one of the following
reasons:
• The NVIC detects that the interrupt signal is high and the interrupt is not active.
• The NVIC detects a rising edge on the interrupt signal.
• Software writes to the corresponding interrupt set-pending register bit, or to the Software Trigger
Interrupt (SWTRIG) register to make a software-generated interrupt pending. See the INT bit in the
PEND0 register or SWTRIG register.
