1018 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
31 :SBUS<n> Commands
:SBUS<n>:NRZ Commands
NOTE
These commands are valid when the automotive NRZ serial decode and triggering option has
been licensed.
Table 127 :SBUS<n>:NRZ Commands Summary
Command Query Options and Query Returns
:SBUS<n>:NRZ:BASE
<base> (see page 1020)
:SBUS<n>:NRZ:BASE?
(see page 1020)
<base> ::= {HEX | DECimal |
ASCii}
:SBUS<n>:NRZ:BAUDrate
<baudrate> (see
page 1021)
:SBUS<n>:NRZ:BAUDrate
? (see page 1021)
<baudrate> ::= integer from 5000
to 5000000 in 100 b/s increments
:SBUS<n>:NRZ:BITorder
<bitorder> (see
page 1022)
:SBUS<n>:NRZ:BITorder
? (see page 1022)
<bitorder> ::= {MSBFirst |
LSBFirst}
:SBUS<n>:NRZ:DISPlay
<format> (see
page 1023)
:SBUS<n>:NRZ:DISPlay?
(see page 1023)
<format> ::= {BIT | WORD}
:SBUS<n>:NRZ:DSIZe
<#words> (see
page 1024)
:SBUS<n>:NRZ:DSIZe?
(see page 1024)
<#words> ::= from 1-255, in NR1
format
:SBUS<n>:NRZ:FSIZe
<#bits> (see
page 1025)
:SBUS<n>:NRZ:FSIZe?
(see page 1025)
<#bits> ::= from 2-255, in NR1
format
:SBUS<n>:NRZ:HSIZe
<#bits> (see
page 1026)
:SBUS<n>:NRZ:HSIZe?
(see page 1026)
<#bits> ::= from 0-32, in NR1
format
:SBUS<n>:NRZ:IDLE:BIT
S <#bits> (see
page 1027)
:SBUS<n>:NRZ:IDLE:BIT
S? (see page 1027)
<#bits> ::= minimum idle time in
terms of bit width, from 1.50 to
32.0, in NR3 format.
:SBUS<n>:NRZ:IDLE:STA
Te <state> (see
page 1028)
:SBUS<n>:NRZ:IDLE:STA
Te? (see page 1028)
<state> ::= {LOW | HIGH}
:SBUS<n>:NRZ:LOGic
<logic> (see
page 1029)
:SBUS<n>:NRZ:LOGic?
(see page 1029)
<logic> ::= {HIGH | LOW}
:SBUS<n>:NRZ:SOURce
<source> (see
page 1030)
:SBUS<n>:NRZ:SOURce?
(see page 1030)
<source> ::= {CHANnel<n> |
DIGital<d>}
