:SEARch Commands 32

Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 1209

:SEARch:SERial:IIC:MODE

(see page 1610)

Command Syntax

:SEARch:SERial:IIC:MODE <value>

<value> ::= {RESTart | ADDRess | ANACk | NACKnowledge | READEprom

| READ7 | WRITE7 | R7Data2 | W7Data2}

The :SEARch:SERial:IIC:MODE command selects the type of IIC information to find

in the Lister display:

• RESTart — searches for another start condition occurring before a stop

condition.

• ADDRess — searches for a packet with the specified address, ignoring the R/W

bit.

• ANACk — searches for address with no acknowledge events.

•NACKnowledge — searches for missing acknowledge events.

• READEprom — searches for EEPROM data reads.

• READ7 — searches for 7-bit address frames containing

Start:Address7:Read:Ack:Data. The value READ is also accepted for READ7.

• WRITe7 — searches for 7-bit address frames containing

Start:Address7:Write:Ack:Data. The value WRITe is also accepted for WRITe7.

• R7Data2 — searches for 7-bit address frames containing

Start:Address7:Read:Ack:Data:Ack:Data2.

• W7Data2 — searches for 7-bit address frames containing

Start:Address7:Write:Ack:Data:Ack:Data2.

When searching for events containing addresses, address values are specified

using the :SEARch:SERial:IIC:PATTern:ADDRess command.

When searching for events containing data, data values are specified using the

:SEARch:SERial:IIC:PATTern:DATA and :SEARch:SERial:IIC:PATTern:DATA2

commands.

Query Syntax

:SEARch:SERial:IIC:MODE?

The :SEARch:SERial:IIC:MODE? query returns the currently selected mode.

Return Format

<value> ::= {REST | ADDR | ANAC | NACK | READE | READ7 | WRITE7

| R7D2 | W7D2}

NOTE

The short form of READ7 (READ7), READEprom (READE), and WRITe7 (WRIT7) do not follow

the defined Long Form to Short Form Truncation Rules (see page 1612).
