:TRIGger Commands 35

Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 1345

:TRIGger:NFC:TEVent

(see page 1610)

Command Syntax

:TRIGger:NFC:TEVent <trigger_event>

<trigger_event> ::= {ATRigger | ASReq | AALLreq | AEITher | ASDDreq

| BSReq | BALLreq | BEITher | BATTrib | FSReq | FAReq | FPReamble}

The :TRIGger:NFC:TEVent command specifies the trigger event. Valid trigger event

settings depend on the signaling technology selected (by

:TRIGger:NFC:STANdard):

Query Syntax

:TRIGger:NFC:TEVent?

The :TRIGger:NFC:TEVent? query returns the specified trigger event.

Return Format

<trigger_event><NL>

<trigger_event> ::= {ATR | ASR | AALL | AEIT | ASDD | BSR | BALL

| BEIT | BATT | FSR | FAR | FPR}

Signaling

Technology

Trigger Event Description

NFC-A ATRigger The arm event is specified by :TRIGger:NFC:AEVent, and the

trigger event is SDD_REQ.

ASReq SENS_REQ

AALLreq ALL_REQ

AEITher Either the SENS_REQ or ALL_REQ events will cause a trigger.

ASDDreq SDD_REQ

NFC-B ATRigger The arm event is specified by :TRIGger:NFC:AEVent, and the

trigger event is ATTRIB.

BSReq SENSB_REQ

BALLreq ALLB_REQ

BEITher Either the SENSB_REQ or ALLB_REQ events will cause a trigger.

BATTrib ATTRIB

NFC-F ATRigger The arm event is specified by :TRIGger:NFC:AEVent, and the

trigger event is ATR_REQ.

FSReq SENSF_REQ

FAReq ATR_REQ

FPReamble The preamble sequence that begins a data frame will cause a

trigger.
