52 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
1 What's New
What's New in Version 4.06
New features in version 4.06 of the InfiniiVision 4000 X-Series oscilloscope
software are:
• The Control Loop Response (Bode) power analysis now lets you select a phase
plot as well as a gain plot.
• The ISO standard for CAN FD is now supported.
• Up to 10 annotations are supported.
More detailed descriptions of the new and changed commands appear below.
New Commands
Changed
Commands
Command Description
:POWer:CLResponse:VIEW When the Control Loop Response (Bode) power analysis is
selected, this command selects whether to display a gain or
phase plot.
:SBUS<n>:CAN:FDSTandard
(see page 888)
Lets you pick the standard that will be used when decoding or
triggering on FD frames, ISO, or non-ISO.
Command Differences
:DISPlay:ANNotation<n> (see
page 404)
You can now define up to 10 annotations.
:DISPlay:ANNotation<n>:BACK
ground (see page 405)
:DISPlay:ANNotation<n>:COLor
(see page 406)
:DISPlay:ANNotation<n>:TEXT
(see page 407)
:DISPlay:ANNotation<n>:X1Pos
ition (see page 408)
:DISPlay:ANNotation<n>:Y1Pos
ition (see page 409)
:SBUS<n>:CAN:TRIGger (see
page 894)
Has some description changes related to the CAN FD ISO support
changes.
