7 Root (:) Commands
:STATus
(see page 1610)
Query Syntax
:STATus? <source>
<source> ::= {CHANnel<n> | FUNCtion<m> | MATH<m> | SBUS{1 | 2}
| WMEMory<r>}
for the DSO models
<source> ::= {CHANnel<n> | DIGital<d> | POD{1 | 2}
| BUS{1 | 2} | FUNCtion<m> | MATH<m> | SBUS{1 | 2}
| WMEMory<r>}
for the MSO models
<n> ::= 1 to (# analog channels) in NR1 format
<d> ::= 0 to (# digital channels - 1) in NR1 format
<m> ::= 1 to (# math functions) in NR1 format
<r> ::= 1 to (# ref waveforms) in NR1 format
The :STATus? query reports whether the channel, function, serial decode bus, or
reference waveform location specified by <source> is displayed.
Return Format
<value><NL>
<value> ::= {1 | 0}
See Also • "Introduction to Root (:) Commands" on page 258
• ":BLANk" on page 266
• ":CHANnel<n>:DISPlay" on page 349
• ":DIGital<d>:DISPlay" on page 395
• ":FUNCtion<m>:DISPlay" on page 469
• ":POD<n>:DISPlay" on page 701
• ":SBUS<n>:DISPlay" on page 856
• ":WMEMory<r>:DISPlay" on page 1484
• ":VIEW" on page 297
NOTE
MATH<m> is an alias for FUNCtion<m>.
