:SAVE Commands 30

Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 825

:SAVE:ARBitrary[:STARt]

(see page 1610)

Command Syntax

:SAVE:ARBitrary:[STARt] [<file_spec>][, <wavegen_id>]

<file_spec> ::= {<internal_loc> | <file_name>}

<internal_loc> ::= 0-3; an integer in NR1 format

<file_name> ::= quoted ASCII string

<wavegen_id> ::= {WGEN1 | WGEN2}

The :SAVE:ARBitrary:[STARt] command saves the current arbitrary waveform to an

internal location or a file on a USB storage device.

The <wavegen_id> parameter specifies which waveform generator to save the

arbitrary waveform from.

See Also • "Introduction to :SAVE Commands" on page 824

• ":SAVE:FILename" on page 827

• ":SAVE:PWD" on page 837

• ":RECall:ARBitrary[:STARt]" on page 812

NOTE

If a file extension is provided as part of a specified <file_name>, it must be ".csv".
