962 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
31 :SBUS<n> Commands
:SBUS<n>:IIC Commands
NOTE
These commands are only valid when the low-speed IIC and SPI serial decode option has been
licensed.
Table 123 :SBUS<n>:IIC Commands Summary
Command Query Options and Query Returns
:SBUS<n>:IIC:ASIZe
<size> (see page 964)
:SBUS<n>:IIC:ASIZe?
(see page 964)
<size> ::= {BIT7 | BIT8}
:SBUS<n>:IIC[:SOURce]
:CLOCk <source> (see
page 965)
:SBUS<n>:IIC[:SOURce]
:CLOCk? (see page 965)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:IIC[:SOURce]
:DATA <source> (see
page 966)
:SBUS<n>:IIC[:SOURce]
:DATA? (see page 966)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:IIC:TRIGger:
PATTern:ADDRess
<value> (see page 967)
:SBUS<n>:IIC:TRIGger:
PATTern:ADDRess? (see
page 967)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:SBUS<n>:IIC:TRIGger:
PATTern:DATA <value>
(see page 968)
:SBUS<n>:IIC:TRIGger:
PATTern:DATA? (see
page 968)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:SBUS<n>:IIC:TRIGger:
PATTern:DATa2 <value>
(see page 969)
:SBUS<n>:IIC:TRIGger:
PATTern:DATa2? (see
page 969)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
