1326 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide

35 :TRIGger Commands

:TRIGger[:EDGE]:LEVel

(see page 1610)

Command Syntax

:TRIGger[:EDGE]:LEVel <level>

<level> ::= <level>[,<source>]

<level> ::= 0.75 x full-scale voltage from center screen in NR3 format

for internal triggers

<level> ::= ±(external range setting) in NR3 format

for external triggers

<level> ::= ±8 V for digital channels (MSO models)

<source> ::= {CHANnel<n> | EXTernal} for the DSO models

<source> ::= {CHANnel<n> | DIGital<d> | EXTernal}

for the MSO models

<n> ::= 1 to (# analog channels) in NR1 format

<d> ::= 0 to (# digital channels - 1) in NR1 format

The :TRIGger[:EDGE]:LEVel command sets the trigger level voltage for the active

trigger source.

Query Syntax

:TRIGger[:EDGE]:LEVel? [<source>]

The :TRIGger[:EDGE]:LEVel? query returns the trigger level of the current trigger

source.

Return Format

See Also • "Introduction to :TRIGger Commands" on page 1295

• ":TRIGger[:EDGE]:SOURce" on page 1329

• ":EXTernal:RANGe" on page 436

• ":POD<n>:THReshold" on page 703

• ":DIGital<d>:THReshold" on page 399

NOTE

If the optional source is specified and is not the active source, the level on the active source is

not affected and the active source is not changed.
