Obsolete and Discontinued Commands 39

Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 1531

:MEASure:VTIMe

(see page 1610)

Query Syntax

:MEASure:VTIMe? <vtime_argument>[,<source>]

<vtime_argument> ::= time from trigger in seconds

<source> ::= {<digital channels> | CHANnel<n> | FUNCtion<m> | MATH<m>

| WMEMory<r>}

<digital channels> ::= DIGital<d> for the MSO models

<d> ::= 0 to (# digital channels - 1) in NR1 format

<n> ::= 1 to (# of analog channels) in NR1 format

<m> ::= 1 to (# math functions) in NR1 format

<r> ::= 1 to (# ref waveforms) in NR1 format

The :MEASure:VTIMe? query returns the vertical value at a specified horizontal

value on the source specified (see also :MEASure:SOURce). The specified

horizontal value must be on the screen; when it is a time value, it is referenced to

the trigger event. If the optional source parameter is specified, the measurement

source is modified.

Return Format

<value> ::= vertical value at the specified horizontal location

in NR3 format

See Also • "Introduction to :MEASure Commands" on page 568

• ":MEASure:SOURce" on page 615

• ":MEASure:TEDGe" on page 623

• ":MEASure:TVALue" on page 626

NOTE

When the source is an FFT (Fast Fourier Transform) waveform, the <vtime_argument> is a

frequency value instead of a time value.
