32 :SEARch Commands
:SEARch:SERial:CAN Commands
Table 140 :SEARch:SERial:CAN Commands Summary
Command Query Options and Query Returns
:SEARch:SERial:CAN:MO
DE <value> (see
page 1187)
:SEARch:SERial:CAN:MO
DE? (see page 1187)
<value> ::= {IDEither | IDData |
DATA | IDRemote | ERRor |
ACKerror | FORMerror | STUFferror
| CRCerror | ALLerrors | OVERload
| MESSage | MSIGnal}
:SEARch:SERial:CAN:PA
TTern:DATA <string>
(see page 1189)
:SEARch:SERial:CAN:PA
TTern:DATA? (see
page 1189)
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X} for
hexadecimal
:SEARch:SERial:CAN:PA
TTern:DATA:LENGth
<length> (see
page 1190)
:SEARch:SERial:CAN:PA
TTern:DATA:LENGth?
(see page 1190)
<length> ::= integer from 1 to 8
in NR1 format
:SEARch:SERial:CAN:PA
TTern:ID <string>
(see page 1191)
:SEARch:SERial:CAN:PA
TTern:ID? (see
page 1191)
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X} for
hexadecimal
:SEARch:SERial:CAN:PA
TTern:ID:MODE <value>
(see page 1192)
:SEARch:SERial:CAN:PA
TTern:ID:MODE? (see
page 1192)
<value> ::= {STANdard | EXTended}
:SEARch:SERial:CAN:SY
MBolic:MESSage <name>
(see page 1193)
:SEARch:SERial:CAN:SY
MBolic:MESSage? (see
page 1193)
<name> ::= quoted ASCII string
:SEARch:SERial:CAN:SY
MBolic:SIGNal <name>
(see page 1194)
:SEARch:SERial:CAN:SY
MBolic:SIGNal? (see
page 1194)
<name> ::= quoted ASCII string
:SEARch:SERial:CAN:SY
MBolic:VALue <data>
(see page 1195)
:SEARch:SERial:CAN:SY
MBolic:VALue? (see
page 1195)
<data> ::= value in NR3 format
