Obsolete and Discontinued Commands 39
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 1505
:DISPlay:ORDer
(see page 1610)
Query Syntax
:DISPlay:ORDer?
The :DISPlay:ORDer? query returns a list of digital channel numbers in screen
order, from top to bottom, separated by commas. Busing is displayed as digital
channels with no separator. For example, in the following list, the bus consists of
digital channels 4 and 5: DIG1, DIG4 DIG5, DIG7.
Return Format
<order><NL>
<order> ::= Unquoted ASCII string
See Also • ":DIGital<d>:POSition" on page 397
Example Code
' DISP_ORDER - Set the order the channels are displayed on the
' analyzer. You can enter between 1 and 32 channels at one time.
' If you leave out channels, they will not be displayed.
' Display ONLY channel 0 and channel 10 in that order.
myScope.WriteString ":DISPLAY:ORDER 0,10"
See complete example programs at: Chapter 44, “Programming Examples,”
starting on page 1619
The :DISPlay:ORDer command is an obsolete command provided for compatibility to previous
oscilloscopes. This command is only available on the MSO models.
A return value is included for each digital channel. A return value of NONE indicates that a
channel is turned off.
