:SBUS<n> Commands 31

Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 857

:SBUS<n>:MODE

(see page 1610)

Command Syntax

:SBUS<n>:MODE <mode>

<mode> ::= {A429 | FLEXray | CAN | CXPI | I2S | IIC | LIN | M1553

| MANChester | NRZ | SENT | SPI | UART | USB | USBPd}

The :SBUS<n>:MODE command determines the decode mode for the serial bus.

Query Syntax

:SBUS<n>:MODE?

The :SBUS<n>:MODE? query returns the current serial bus decode mode setting.

Return Format

<mode> ::= {A429 | FLEX | CAN | CXPI | I2S | IIC | LIN | M1553 | MANC

| NRZ | SENT | SPI | UART | USB | USBP | NONE}

Errors • "-241, Hardware missing" on page 1551

See Also • "Introduction to :SBUS<n> Commands" on page 853

• ":SBUS<n>:A429 Commands" on page 858

• ":SBUS<n>:CAN Commands" on page 877

• ":SBUS<n>:FLEXray Commands" on page 924

• ":SBUS<n>:I2S Commands" on page 943

• ":SBUS<n>:IIC Commands" on page 962

• ":SBUS<n>:LIN Commands" on page 973

• ":SBUS<n>:M1553 Commands" on page 992

• ":SBUS<n>:SENT Commands" on page 1037

• ":SBUS<n>:SPI Commands" on page 1073

• ":SBUS<n>:UART Commands" on page 1090

• ":SBUS<n>:USB Commands" on page 1112

NOTE

This command is only valid when a serial decode option has been licensed.
