44 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
1 What's New
What's New in Version 7.10
New features in version 7.10 of the InfiniiVision 4000 X-Series oscilloscope
software are:
Random trigger holdoff mode.
FFT detectors are added.
FFT measurements are added: Adjacent Channel Power Ratio (ACPR), Channel
Power, Occupied Bandwidth, and Total Harmonic Distortion.
Frequency Response Analysis feature is added.
More detailed descriptions of the new and changed commands appear below.
New Commands
Command Description
:DISPlay:GRATicule:ALABels
(see page 414)
Turns graticule (grid) axis labels on or off.
:DISPlay:GRATicule:INTensity
(see page 415)
Sets the graticule (grid) intensity.
:DISPlay:GRATicule:TYPE (see
page 416)
Sets the graticule (grid) type.
:FRANalysis Commands (see
page 439)
Commands for using the Frequency Response Analysis feature.
:FUNCtion<m>[:FFT]:BSIZe?
(see page 470)
Returns the Bin Size setting for the FFT.
:FUNCtion<m>[:FFT]:DETection
:POINts (see page 472)
Specifies the maximum number of points that the FFT detector
should decimate to.
:FUNCtion<m>[:FFT]:DETection
:TYPE (see page 473)
Sets the FFT detector decimation type.
:FUNCtion<m>[:FFT]:RBWidth?
(see page 478)
Returns the Resolution Bandwidth setting for the FFT.
:FUNCtion<m>[:FFT]:READout<
n> (see page 479)
For the FFT, selects from these types of readouts: Resolution
Bandwidth, Bin Size, or Sample Rate.
:FUNCtion<m>[:FFT]:SRATe?
(see page 481)
Returns the Sample Rate setting for the FFT.
:HCOPY:SDUMp:DATA? (see
page 521)
Reads screen image data.
:HCOPY:SDUMp:FORMat (see
page 522)
Specifies the format for screen image data: 24-bit PNG, 24-bit
BMP, or 8-bit BMP8bit.
:MEASure:DELay:DEFine (see
page 582)
Defines slope directions and edge numbers for the
:MEASure:DELay command.
