640 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide

24 :MEASure Commands

:MEASure:YATX

(see page 1610)

Command Syntax

:MEASure:YATX <horiz_location>[,<source>]

<horiz_location> ::= time from trigger in seconds

<source> ::= {<digital channels> | CHANnel<n> | FUNCtion<m> | MATH<m>

| WMEMory<r>}

<digital channels> ::= DIGital<d> for the MSO models

<d> ::= 0 to (# digital channels - 1) in NR1 format

<n> ::= 1 to (# of analog channels) in NR1 format

<m> ::= 1 to (# math functions) in NR1 format

<r> ::= 1 to (# ref waveforms) in NR1 format

The :MEASure:YATX command installs a screen measurement of the vertical value

at a specified horizontal value on the source specified (see also

:MEASure:SOURce).

The specified horizontal value must be on the screen; when it is a time value, it is

referenced to the trigger event. If the optional source parameter is specified, the

measurement source is modified.

Query Syntax

:MEASure:YATX? <horiz_location>[,<source>]

The :MEASure:YATX? query returns the vertical value at a specified horizontal value

on the source specified (see also :MEASure:SOURce).

Return Format

<value> ::= vertical value at the specified horizontal location

in NR3 format

See Also • "Introduction to :MEASure Commands" on page 568

• ":MEASure:SOURce" on page 615

• ":MEASure:TEDGe" on page 623

• ":MEASure:TVALue" on page 626

NOTE

When the source is an FFT (Fast Fourier Transform) waveform, the <horiz_location> is a

frequency value instead of a time value.
