Keysight Technologies InfiniiVision 4000 X Series

104 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
5 Commands Quick Reference
n/a :TER? (see page 296) {0 | 1}
:VIEW <source> (see
page 297)
n/a <source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> | SBUS{1 |
2} | WMEMory<r>} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | POD{1 | 2} | BUS{1 |
2} | FUNCtion<m> | MATH<m> |
SBUS{1 | 2} | WMEMory<r>} for MSO
models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
Table 3 Root (:) Commands Summary (continued)
Command Query Options and Query Returns
Table 4 :ACQuire Commands Summary
Command Query Options and Query Returns
n/a :ACQuire:AALias? (see
page 302)
{1 | 0}
:ACQuire:COMPlete
<complete> (see
page 303)
:ACQuire:COMPlete?
(see page 303)
<complete> ::= 100; an integer in
NR1 format
:ACQuire:COUNt
<count> (see page 304)
:ACQuire:COUNt? (see
page 304)
<count> ::= an integer from 2 to
65536 in NR1 format
:ACQuire:DAALias
<mode> (see page 305)
:ACQuire:DAALias?
(see page 305)
<mode> ::= {DISable | AUTO}
:ACQuire:DIGitizer
{{0 | OFF} | {1 |
ON}} (see page 306)
:ACQuire:DIGitizer?
(see page 306)
{0 | 1}
:ACQuire:MODE <mode>
(see page 307)
:ACQuire:MODE? (see
page 307)
<mode> ::= {RTIMe | ETIMe |
SEGMented}
:ACQuire:POINts[:ANAL
og] <points> (see
page 308)
:ACQuire:POINts[:ANAL
og]? (see page 308)
<points> ::= {AUTO |
<points_value>}
<points_value> ::= desired
analog memory depth in integer
NR1 format
