Commands Quick Reference 5
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 103
:OVLenable <mask>
(see page 286)
:OVLenable? (see
page 287)
<mask> ::= 16-bit integer in NR1
format as shown:
Bit Weight Input
--- ------ ----------
10 1024 Ext Trigger Fault
9 512 Channel 4 Fault
8 256 Channel 3 Fault
7 128 Channel 2 Fault
6 64 Channel 1 Fault
4 16 Ext Trigger OVL
3 8 Channel 4 OVL
2 4 Channel 3 OVL
1 2 Channel 2 OVL
0 1 Channel 1 OVL
n/a :OVLRegister? (see
page 288)
<value> ::= integer in NR1
format. See OVLenable for <value>
:PRINt [<options>]
(see page 290)
n/a <options> ::= [<print
option>][,..,<print option>]
<print option> ::= {COLor |
GRAYscale | PRINter0 | BMP8bit |
BMP | PNG | NOFactors | FACTors}
<print option> can be repeated up
to 5 times.
:RUN (see page 291) n/a n/a
n/a :SERial (see page 292) <return value> ::= unquoted
string containing serial number
:SINGle (see page 293) n/a n/a
n/a :STATus? <display>
(see page 294)
{0 | 1}
<display> ::= {CHANnel<n> |
DIGital<d> | POD{1 | 2} | BUS{1 |
2} | FUNCtion<m> | MATH<m> |
SBUS{1 | 2} | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
:STOP (see page 295) n/a n/a
Table 3 Root (:) Commands Summary (continued)
Command Query Options and Query Returns
