1350 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
35 :TRIGger Commands
:TRIGger:OR Commands
Table 158 :TRIGger:OR Commands Summary
Command Query Options and Query Returns
:TRIGger:OR <string>
(see page 1351)
:TRIGger:OR? (see
page 1351)
<string> ::= "nn...n" where n ::=
{R | F | E | X}
R = rising edge, F = falling
edge, E = either edge, X = don't
care.
Each character in the string is
for an analog or digital channel
as shown on the front panel
display.
