:SEARch:SERial:LIN Commands
Table 144 :SEARch:SERial:LIN Commands Summary
Command Query Options and Query Returns
:SEARch:SERial:LIN:ID
<value> (see
page 1216)
:SEARch:SERial:LIN:ID
? (see page 1216)
<value> ::= 7-bit integer in
decimal, <nondecimal>, or
<string> from 0-63 or 0x00-0x3f
<nondecimal> ::= #Hnn where n ::=
{0,..,9 | A,..,F} for hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
<string> ::= "0xnn" where n ::=
{0,..,9 | A,..,F} for hexadecimal
:SEARch:SERial:LIN:MO
DE <value> (see
page 1217)
:SEARch:SERial:LIN:MO
DE? (see page 1217)
<value> ::= {ID | DATA | ERRor}
:SEARch:SERial:LIN:PA
TTern:DATA <string>
(see page 1218)
:SEARch:SERial:LIN:PA
TTern:DATA? (see
page 1218)
When
:SEARch:SERial:LIN:PATTern:FORMa
t DECimal, <string> ::= "n" where
n ::= 32-bit integer in unsigned
decimal, returns "$" if data has
any don't cares
When
:SEARch:SERial:LIN:PATTern:FORMa
t HEX, <string> ::= "0xnn...n"
where n ::= {0,..,9 | A,..,F | X
}
:SEARch:SERial:LIN:PA
TTern:DATA:LENGth
<length> (see
page 1219)
:SEARch:SERial:LIN:PA
TTern:DATA:LENGth?
(see page 1219)
<length> ::= integer from 1 to 8
in NR1 format
:SEARch:SERial:LIN:PA
TTern:FORMat <base>
(see page 1220)
:SEARch:SERial:LIN:PA
TTern:FORMat? (see
page 1220)
<base> ::= {HEX | DECimal}
:SEARch:SERial:LIN:SY
MBolic:FRAMe <name>
(see page 1221)
:SEARch:SERial:LIN:SY
MBolic:FRAMe? (see
page 1221)
<name> ::= quoted ASCII string
:SEARch:SERial:LIN:SY
MBolic:SIGNal <name>
(see page 1222)
:SEARch:SERial:LIN:SY
MBolic:SIGNal? (see
page 1222)
<name> ::= quoted ASCII string
:SEARch:SERial:LIN:SY
MBolic:VALue <data>
(see page 1223)
:SEARch:SERial:LIN:SY
MBolic:VALue? (see
page 1223)
<data> ::= value in NR3 format
