:TRIGger:DELay Commands
The :TRIGger:DELay:ARM:SOURce and :TRIGger:DELay:TRIGger:SOURce
commands are used to specify the source channel for the arming edge and the
trigger edge in the Edge Then Edge trigger.
If an analog channel is selected as a source, the :TRIGger:EDGE:LEVel command is
used to set the trigger level.
If a digital channel is selected as the source, the :DIGital<n>:THReshold or
:POD<n>:THReshold command is used to set the trigger level.
Table 153 :TRIGger:DELay Commands Summary
Command Query Options and Query Returns
:TRIGger:DELay:ARM:SL
OPe <slope> (see
page 1312)
:TRIGger:DELay:ARM:SL
OPe? (see page 1312)
<slope> ::= {NEGative | POSitive}
:TRIGger:DELay:ARM:SO
URce <source> (see
page 1313)
:TRIGger:DELay:ARM:SO
URce? (see page 1313)
<source> ::= {CHANnel<n> |
DIGital<d>}
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:TRIGger:DELay:TDELay
:TIME <time_value>
(see page 1314)
:TRIGger:DELay:TDELay
:TIME? (see page 1314)
<time_value> ::= time in seconds
in NR3 format
:TRIGger:DELay:TRIGge
r:COUNt <count> (see
page 1315)
:TRIGger:DELay:TRIGge
r:COUNt? (see
page 1315)
<count> ::= integer in NR1 format
:TRIGger:DELay:TRIGge
r:SLOPe <slope> (see
page 1316)
:TRIGger:DELay:TRIGge
r:SLOPe? (see
page 1316)
<slope> ::= {NEGative | POSitive}
:TRIGger:DELay:TRIGge
r:SOURce <source>
(see page 1317)
:TRIGger:DELay:TRIGge
r:SOURce? (see
page 1317)
<source> ::= {CHANnel<n> |
DIGital<d>}
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
