:SBUS<n> Commands 31
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 1137
:SBUS<n>:USBPd Commands
NOTE
These commands are valid when the USB PD (Power Delivery) serial decode and triggering
option has been licensed.
Table 132 :SBUS<n>:USBPd Commands Summary
Command Query Options and Query Returns
:SBUS<n>:USBPd:SOURce
<source> (see
page 1138)
:SBUS<n>:USBPd:SOURce
? (see page 1138)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:USBPd:TRIGge
r <mode> (see
page 1139)
:SBUS<n>:USBPd:TRIGge
r? (see page 1139)
<mode> ::= {PSTart | EOP | SOP |
SPRime | SDPRime | SPDebug |
SDPDebug | HRST | CRST | CRCerror
| PERRor | HEADer}
:SBUS<n>:USBPd:TRIGge
r:HEADer <type> (see
page 1140)
:SBUS<n>:USBPd:TRIGge
r:HEADer? (see
page 1140)
<type> ::= {CMESsage | DMESsage |
EMESsage | VALue}
:SBUS<n>:USBPd:TRIGge
r:HEADer:CMESsage
<type> (see page 1142)
:SBUS<n>:USBPd:TRIGge
r:HEADer:CMESsage?
(see page 1142)
<type> ::= {GOODcrc | GOTOmin |
ACCept | REJect | PING | PSRDy |
GSRCap | GSNCap | DRSWap | PRSWap
| VCSWap | WAIT | SRST | GSCX |
GSTatus | FRSWap | GPSTatus |
GCCodes}
:SBUS<n>:USBPd:TRIGge
r:HEADer:DMESsage
<type> (see page 1144)
:SBUS<n>:USBPd:TRIGge
r:HEADer:DMESsage?
(see page 1144)
<type> ::= {SRCap | REQuest |
BIST | SNCap | BSTatus | ALERt |
GCINfo | VDEFined}
:SBUS<n>:USBPd:TRIGge
r:HEADer:EMESsage
<type> (see page 1145)
:SBUS<n>:USBPd:TRIGge
r:HEADer:EMESsage?
(see page 1145)
<type> ::= {SCX | STATus | GBCap
| GBSTatus | BCAP | GMINfo |
MINFo | SREQuest | SRESponse |
FREQuest | FRESponse | PSTatus |
CINFo | CCODes}
:SBUS<n>:USBPd:TRIGge
r:HEADer:VALue
<string> (see
page 1147)
:SBUS<n>:USBPd:TRIGge
r:HEADer:VALue? (see
page 1147)
<string> ::= "nn...n" where n ::=
{0 | 1 | X}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X}
:SBUS<n>:USBPd:TRIGge
r:HEADer:QUALifier
<type> (see page 1148)
:SBUS<n>:USBPd:TRIGge
r:HEADer:QUALifier?
(see page 1148)
<type> ::= {NONE | SOP | SPRime |
SDPRime}
