638 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide

24 :MEASure Commands

:MEASure:XMAX

(see page 1610)

Command Syntax

:MEASure:XMAX [<source>]

<source> ::= {CHANnel<n> | FUNCtion<m> | MATH<m> | WMEMory<r>}

<n> ::= 1-2 or 1-4 (# of analog channels) in NR1 format

<m> ::= 1 to (# math functions) in NR1 format

<r> ::= 1 to (# ref waveforms) in NR1 format

The :MEASure:XMAX command installs a screen measurement and starts an

X-at-Max-Y measurement on the selected window. If the optional source

parameter is specified, the current source is modified.

Query Syntax

:MEASure:XMAX? [<source>]

The :MEASure:XMAX? query measures and returns the horizontal axis value at

which the maximum vertical value occurs. If the optional source is specified, the

current source is modified.

Return Format

<value> ::= horizontal value of the maximum in NR3 format

See Also • "Introduction to :MEASure Commands" on page 568

• ":MEASure:XMIN" on page 639

• ":MEASure:TMAX" on page 1522

NOTE

:MEASure:XMAX is an alias for :MEASure:TMAX.
