352 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide

11 :CHANnel<n> Commands

:CHANnel<n>:LABel

(see page 1610)

Command Syntax

:CHANnel<n>:LABel <string>

<string> ::= quoted ASCII string

<n> ::= 1 to (# analog channels) in NR1 format

The :CHANnel<n>:LABel command sets the analog channel label to the string that

follows. Setting a label for a channel also adds the name to the label list in

non-volatile memory (replacing the oldest label in the list).

Query Syntax

:CHANnel<n>:LABel?

The :CHANnel<n>:LABel? query returns the label associated with a particular

analog channel.

Return Format

<string> ::= quoted ASCII string

See Also • "Introduction to :CHANnel<n> Commands" on page 345

• ":DISPlay:LABel" on page 418

• ":DIGital<d>:LABel" on page 396

• ":DISPlay:LABList" on page 419

• ":BUS<n>:LABel" on page 328

Example Code

' LABEL - This command allows you to write a name (32 characters

' maximum) next to the channel number. It is not necessary, but

' can be useful for organizing the display.

myScope.WriteString ":CHANnel1:LABel ""CAL 1""" ' Label ch1 "CAL 1".

myScope.WriteString ":CHANnel2:LABel ""CAL2""" ' Label ch1 "CAL2".

See complete example programs at: Chapter 44, “Programming Examples,”

starting on page 1619

NOTE

Label strings are 32 characters or less, and may contain any commonly used ASCII characters.

Labels with more than 32 characters are truncated to 32 characters. Lower case characters

are converted to upper case.
