31 :SBUS<n> Commands
:SBUS<n>:USB Commands
NOTE
These commands are only valid when a USB 2.0 triggering and serial decode option has been
licensed.
Table 131 :SBUS<n>:USB Commands Summary
Command Query Options and Query Returns
:SBUS<n>:USB:BASE
<base> (see page 1115)
:SBUS<n>:USB:BASE?
(see page 1115)
<base> ::= {ASCii | BINary |
DECimal | HEX}
:SBUS<n>:USB:SOURce:D
MINus <source> (see
page 1116)
:SBUS<n>:USB:SOURce:D
MINus? (see page 1116)
<source> ::= {CHANnel<n>} for DSO
models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:USB:SOURce:D
PLus <source> (see
page 1117)
:SBUS<n>:USB:SOURce:D
PLus? (see page 1117)
<source> ::= {CHANnel<n>} for DSO
models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:USB:SOURce:D
IFFerential <source>
(see page 1118)
:SBUS<n>:USB:SOURce:D
IFFerential? (see
page 1118)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:USB:SPEed
<speed> (see
page 1119)
:SBUS<n>:USB:SPEed?
(see page 1119)
<speed> ::= {LOW | FULL | HIGH}
:SBUS<n>:USB:TRIGger
<condition> (see
page 1120)
:SBUS<n>:USB:TRIGger?
(see page 1120)
<condition> ::= {SOP | EOP |
ENTersuspend | EXITsuspend |
RESet | TOKen | DATA | HANDshake
| SPECial | ALLerrors | PIDerror
| CRC5error | CRC16error |
GLITcherror | STUFFerror |
SE1error}
