:SBUS<n> Commands 31

Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 959

:SBUS<n>:I2S:TRIGger:RANGe

(see page 1610)

Command Syntax

:SBUS<n>:I2S:TRIGger:RANGe <lower>,<upper>

<lower> ::= 32-bit integer in signed decimal, <nondecimal>

or <string>

<upper> ::= 32-bit integer in signed decimal, <nondecimal>,

or <string>

<nondecimal> ::= #Hnn...n where n ::= {0,..,9 | A,..,F}

for hexadecimal

<nondecimal> ::= #Bnn...n where n ::= {0 | 1} for binary

<string> ::= "0xnn...n" where n ::= {0,..,9 | A,..,F} for hexadecimal

The :SBUS<n>:I2S:TRIGger:RANGe command sets the lower and upper range

boundaries used by the INRange, OUTRange, INCReasing, and DECReasing

trigger conditions. You can enter the parameters in any order — the smaller value

becomes the <lower> and the larger value becomes the <upper>.

Note that for INCReasing and DECReasing, the <lower> and <upper> values

correspond to the "Armed" and "Trigger" softkeys.

Query Syntax

:SBUS<n>:I2S:TRIGger:RANGe?

The :SBUS<n>:I2S:TRIGger:RANGe? query returns the currently set lower and

upper range boundaries.

Return Format

<lower> ::= 32-bit integer in signed decimal

<upper> ::= 32-bit integer in signed decimal

See Also • "Introduction to :TRIGger Commands" on page 1295

• ":SBUS<n>:I2S:TRIGger" on page 953

• ":SBUS<n>:I2S:RWIDth" on page 949

• ":SBUS<n>:I2S:TWIDth" on page 960

• ":SBUS<n>:I2S:WSLow" on page 961

NOTE

The length of the <lower> and <upper> values is determined by the :SBUS<n>:I2S:RWIDth

and :SBUS<n>:I2S:TWIDth commands. When the receiver word size is less than the

transmitter word size, the length is equal to the receiver word size. When the receiver word

size is greater than the transmitter word size, the length is equal to the transmitter word size.
