:MEASure Commands 24

Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 573

:MEASure:BWIDth

(see page 1610)

Command Syntax

:MEASure:BWIDth [<source>]

<source> ::= {CHANnel<n> | FUNCtion<m> | MATH<m> | WMEMory<r>}

<n> ::= 1 to (# analog channels) in NR1 format

<m> ::= 1 to (# math functions) in NR1 format

<r> ::= 1 to (# ref waveforms) in NR1 format

The :MEASure:BWIDth command installs a burst width measurement on screen. If

the optional source parameter is not specified, the current measurement source is

used.

Query Syntax

:MEASure:BWIDth? [<source>]

The :MEASure:BWIDth? query measures and returns the width of the burst on the

screen.

The burst width is calculated as follows:

burst width = (last edge on screen - first edge on screen)

Return Format

<value> ::= burst width in seconds in NR3 format

See Also • "Introduction to :MEASure Commands" on page 568

• ":MEASure:SOURce" on page 615

NOTE

This command is not available if the source is FFT (Fast Fourier Transform).
