Keysight InfiniiVision 4000 X-Series Oscilloscopes
Programmer's Guide
19 :FRANalysis Commands
Control oscilloscope functions associated with the Frequency Response Analysis
(FRA) feature, which is available in oscilloscope models that have a
license-enabled built-in waveform generator. See "Introduction to :FRANalysis
Commands" on page 440.
Table 105 :FRANalysis Commands Summary
Command Query Options and Query Returns
n/a :FRANalysis:DATA?
[SWEep | SINGle] (see
page 441)
<binary_block> ::=
comma-separated data with
newlines at the end of each row
:FRANalysis:ENABle
{{0 | OFF} | {1 |
ON}} (see page 442)
:FRANalysis:ENABle?
(see page 442)
{0 | 1}
:FRANalysis:FREQuency
:MODE <setting> (see
page 443)
:FRANalysis:FREQuency
:MODE? (see page 443)
<setting> ::= {SWEep | SINGle}
:FRANalysis:FREQuency
:SINGle
<value>[suffix] (see
page 444)
:FRANalysis:FREQuency
:SINGle? (see
page 444)
<value> ::= {20 | 100 | 1000 |
10000 | 100000 | 1000000 |
10000000 | 2000000}
[suffix] ::= {Hz | kHz| MHz}
:FRANalysis:FREQuency
:STARt
<value>[suffix] (see
page 445)
:FRANalysis:FREQuency
:STARt? (see page 445)
<value> ::= {20 | 100 | 1000 |
10000 | 100000 | 1000000 |
10000000}
[suffix] ::= {Hz | kHz| MHz}
:FRANalysis:FREQuency
:STOP <value>[suffix]
(see page 446)
:FRANalysis:FREQuency
:STOP? (see page 446)
<value> ::= {100 | 1000 | 10000 |
100000 | 1000000 | 10000000 |
20000000}
[suffix] ::= {Hz | kHz| MHz}
:FRANalysis:PPDecade
<value> (see page 447)
:FRANalysis:PPDecade?
(see page 447)
<value> ::= {10 | 20 | 30 | 40 |
50 | 60 | 70 | 80 | 90 | 100}
:FRANalysis:RUN (see
page 448)
n/a n/a
