What's New 1
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 43
Changed
Commands
Command Differences
:DEMO:FUNCtion (see
page 386)
The USBPd function is now available.
:RECall:WMEMory<r>:[STARt]
(see page 819)
There is now a <data> option for recalling waveform data from the
controller PC.
:SBUS<n>:A429:SPEed (see
page 869)
The USER option is now available to select a user-defined baud
rate.
:SBUS<n>:MANChester:BAUDr
ate (see page 1002)
The minimum baud rate is changed from "2000" to "500".
:SBUS<n>:MODE (see
page 857)
The USBPd mode is now available with the USB PD serial decode
and triggering license.
:SBUS<n>:SENT:PPULse (see
page 1048)
The pause mode now, in addition supporting pause pulses off and
on, supports SENT SPC (Short PWM Code) where message events
are triggered by the master.
