164 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
5 Commands Quick Reference
:SAVE:WMEMory:SOURce
<source> (see
page 850)
:SAVE:WMEMory:SOURce?
(see page 850)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
NOTE: Only ADD or SUBtract math
operations can be saved as
reference waveforms.
<return_value> ::= <source>
:SAVE:WMEMory[:STARt]
[<file_name>] (see
page 851)
n/a <file_name> ::= quoted ASCII
string
If extension included in file
name, it must be ".h5".
Table 26 :SAVE Commands Summary (continued)
Command Query Options and Query Returns
Table 27 General :SBUS<n> Commands Summary
Command Query Options and Query Returns
:SBUS<n>:DISPlay {{0
| OFF} | {1 | ON}}
(see page 856)
:SBUS<n>:DISPlay?
(see page 856)
{0 | 1}
:SBUS<n>:MODE <mode>
(see page 857)
:SBUS<n>:MODE? (see
page 857)
<mode> ::= {A429 | CAN | CXPI |
FLEXray | I2S | IIC | LIN | M1553
| MANChester | NRZ | SENT | SPI |
UART | USB | USBPd}
Table 28 :SBUS<n>:A429 Commands Summary
Command Query Options and Query Returns
:SBUS<n>:A429:AUToset
up (see page 860)
n/a n/a
:SBUS<n>:A429:BASE
<base> (see page 861)
:SBUS<n>:A429:BASE?
(see page 861)
<base> ::= {BINary | HEX}
:SBUS<n>:A429:BAUDrat
e <baudrate> (see
page 862)
:SBUS<n>:A429:BAUDrat
e? (see page 862)
<baudrate> ::= integer from 10000
to 1000000
