Keysight Technologies InfiniiVision 4000 X Series

528 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
23 :MARKer Commands
:MARKer:X2Position
<position>[suffix]
(see page 536)
:MARKer:X2Position?
(see page 536)
<position> ::= X2 cursor position
value in NR3 format
[suffix] ::= {s | ms | us | ns |
ps | Hz | kHz | MHz}
<return_value> ::= X2 cursor
position value in NR3 format
:MARKer:X2Y2source
<source> (see
page 537)
:MARKer:X2Y2source?
(see page 537)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= <source>
n/a :MARKer:XDELta? (see
page 538)
<return_value> ::= X cursors
delta value in NR3 format
:MARKer:XUNits <mode>
(see page 539)
:MARKer:XUNits? (see
page 539)
<units> ::= {SEConds | HERTz |
DEGRees | PERCent}
:MARKer:XUNits:USE
(see page 540)
n/a n/a
:MARKer:Y1:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 541)
:MARKer:Y1:DISPlay?
(see page 541)
<setting> ::= {0 | 1}
:MARKer:Y1Position
<position>[suffix]
(see page 542)
:MARKer:Y1Position?
(see page 542)
<position> ::= Y1 cursor position
value in NR3 format
[suffix] ::= {V | mV | dB}
<return_value> ::= Y1 cursor
position value in NR3 format
:MARKer:Y2:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 543)
:MARKer:Y2:DISPlay?
(see page 543)
<setting> ::= {0 | 1}
:MARKer:Y2Position
<position>[suffix]
(see page 544)
:MARKer:Y2Position?
(see page 544)
<position> ::= Y2 cursor position
value in NR3 format
[suffix] ::= {V | mV | dB}
<return_value> ::= Y2 cursor
position value in NR3 format
Table 109 :MARKer Commands Summary (continued)
Command Query Options and Query Returns
