974 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
31 :SBUS<n> Commands
:SBUS<n>:LIN:TRIGger:
ID <value> (see
page 984)
:SBUS<n>:LIN:TRIGger:
ID? (see page 984)
<value> ::= 7-bit integer in
decimal, <nondecimal>, or
<string> from 0-63 or 0x00-0x3f
<nondecimal> ::= #Hnn where n ::=
{0,..,9 | A,..,F} for hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
<string> ::= "0xnn" where n ::=
{0,..,9 | A,..,F} for hexadecimal
:SBUS<n>:LIN:TRIGger:
PATTern:DATA <string>
(see page 985)
:SBUS<n>:LIN:TRIGger:
PATTern:DATA? (see
page 985)
<string> ::= "n" where n ::=
32-bit integer in unsigned
decimal when <base> = DECimal
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $} when <base> =
BINary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
when <base> = HEX
:SBUS<n>:LIN:TRIGger:
PATTern:DATA:LENGth
<length> (see
page 987)
:SBUS<n>:LIN:TRIGger:
PATTern:DATA:LENGth?
(see page 987)
<length> ::= integer from 1 to 8
in NR1 format
:SBUS<n>:LIN:TRIGger:
PATTern:FORMat <base>
(see page 988)
:SBUS<n>:LIN:TRIGger:
PATTern:FORMat? (see
page 988)
<base> ::= {BINary | HEX |
DECimal}
:SBUS<n>:LIN:TRIGger:
SYMBolic:FRAMe <name>
(see page 989)
:SBUS<n>:LIN:TRIGger:
SYMBolic:FRAMe? (see
page 989)
<name> ::= quoted ASCII string
:SBUS<n>:LIN:TRIGger:
SYMBolic:SIGNal
<name> (see page 990)
:SBUS<n>:LIN:TRIGger:
SYMBolic:SIGNal? (see
page 990)
<name> ::= quoted ASCII string
:SBUS<n>:LIN:TRIGger:
SYMBolic:VALue <data>
(see page 991)
:SBUS<n>:LIN:TRIGger:
SYMBolic:VALue? (see
page 991)
<data> ::= value in NR3 format
Table 124 :SBUS<n>:LIN Commands Summary (continued)
Command Query Options and Query Returns
