Keysight Technologies InfiniiVision 4000 X Series

108 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
5 Commands Quick Reference
:CHANnel<n>:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 349)
:CHANnel<n>:DISPlay?
(see page 349)
{0 | 1}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:IMPedance
<impedance> (see
page 350)
:CHANnel<n>:IMPedance
? (see page 350)
<impedance> ::= {ONEMeg | FIFTy}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:INVert
{{0 | OFF} | {1 |
ON}} (see page 351)
:CHANnel<n>:INVert?
(see page 351)
{0 | 1}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:LABel
<string> (see
page 352)
:CHANnel<n>:LABel?
(see page 352)
<string> ::= any series of 32 or
less ASCII characters enclosed in
quotation marks
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:OFFSet
<offset>[suffix] (see
page 353)
:CHANnel<n>:OFFSet?
(see page 353)
<offset> ::= Vertical offset
value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1-2 or 1-4; in NR1 format
:CHANnel<n>:PROBe
<attenuation> (see
page 354)
:CHANnel<n>:PROBe?
(see page 354)
<attenuation> ::= Probe
attenuation ratio in NR3 format
<n> ::= 1-2 or 1-4; in NR1 format
:CHANnel<n>:PROBe:HEA
D[:TYPE] <head_param>
(see page 355)
:CHANnel<n>:PROBe:HEA
D[:TYPE]? (see
page 355)
<head_param> ::= {SEND0 | SEND6 |
SEND12 | SEND20 | DIFF0 | DIFF6 |
DIFF12 | DIFF20 | DSMA | DSMA6 |
NONE}
<n> ::= 1 to (# analog channels)
in NR1 format
n/a :CHANnel<n>:PROBe:ID?
(see page 356)
<probe id> ::= unquoted ASCII
string up to 11 characters
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:PROBe:MMO
Del <value> (see
page 357)
:CHANnel<n>:PROBe:MMO
Del? (see page 357)
<value> ::= {P5205 | P5210 |
P6205 | P6241 | P6243 | P6245 |
P6246 | P6247 | P6248 | P6249 |
P6250 | P6251 | P670X | P671X |
TCP202}
<n> ::= 1 to (# analog channels)
in NR1 format
Table 7 :CHANnel<n> Commands Summary (continued)
Command Query Options and Query Returns
