Keysight Technologies InfiniiVision 4000 X Series

Commands Quick Reference 5
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 109
:CHANnel<n>:PROBe:RSE
Nse <value> (see
page 358)
:CHANnel<n>:PROBe:RSE
Nse? (see page 358)
<value> ::= Ohms in NR3 format
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:PROBe:SKE
W <skew_value> (see
page 359)
:CHANnel<n>:PROBe:SKE
W? (see page 359)
<skew_value> ::= -100 ns to +100
ns in NR3 format
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:PROBe:STY
Pe <signal type> (see
page 360)
:CHANnel<n>:PROBe:STY
Pe? (see page 360)
<signal type> ::= {DIFFerential |
SINGle}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:PROBe:ZOO
M {{0 | OFF} | {1 |
ON}} (see page 361)
:CHANnel<n>:PROBe:ZOO
M? (see page 361)
<setting> ::= {0 | 1}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:PROTectio
n (see page 362)
:CHANnel<n>:PROTectio
n? (see page 362)
{NORM | TRIP}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:RANGe
<range>[suffix] (see
page 363)
:CHANnel<n>:RANGe?
(see page 363)
<range> ::= Vertical full-scale
range value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:SCALe
<scale>[suffix] (see
page 364)
:CHANnel<n>:SCALe?
(see page 364)
<scale> ::= Vertical units per
division value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:UNITs
<units> (see page 365)
:CHANnel<n>:UNITs?
(see page 365)
<units> ::= {VOLT | AMPere}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:VERNier
{{0 | OFF} | {1 |
ON}} (see page 366)
:CHANnel<n>:VERNier?
(see page 366)
{0 | 1}
<n> ::= 1 to (# analog channels)
in NR1 format
Table 7 :CHANnel<n> Commands Summary (continued)
Command Query Options and Query Returns
