116 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
5 Commands Quick Reference
:FRANalysis:RUN (see
page 448)
n/a n/a
:FRANalysis:SOURce:IN
Put <source> (see
page 449)
:FRANalysis:SOURce:IN
Put? (see page 449)
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
:FRANalysis:SOURce:OU
TPut <source> (see
page 450)
:FRANalysis:SOURce:OU
TPut? (see page 450)
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
:FRANalysis:TRACe
<selection> (see
page 451)
:FRANalysis:TRACe?
(see page 451)
<selection> ::= {NONE | ALL |
GAIN | PHASe}[,{GAIN | PHASe}]
:FRANalysis:WGEN:LOAD
<impedance> (see
page 452)
:FRANalysis:WGEN:LOAD
? (see page 452)
<impedance> ::= {ONEMeg | FIFTy}
:FRANalysis:WGEN:VOLT
age
<amplitude>,[<range>]
(see page 453)
:FRANalysis:WGEN:VOLT
age? [<range>] (see
page 453)
<amplitude> ::= amplitude in
volts in NR3 format
<range> ::= {F20HZ | F100HZ |
F1KHZ | F10KHZ | F100KHZ | F1MHZ
| F10MHZ | F20MHZ}
:FRANalysis:WGEN:VOLT
age:PROFile {{0 |
OFF} | {1 | ON}} (see
page 454)
:FRANalysis:WGEN:VOLT
age:PROFile? (see
page 454)
{0 | 1}
Table 15 :FRANalysis Commands Summary (continued)
Command Query Options and Query Returns
Table 16 :FUNCtion<m> Commands Summary
Command Query Options and Query Returns
:FUNCtion<m>:AVERage:
COUNt <count> (see
page 462)
:FUNCtion<m>:AVERage:
COUNt? (see page 462)
<count> ::= an integer from 2 to
65536 in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:BUS:CLOC
k <source> (see
page 463)
:FUNCtion<m>:BUS:CLOC
k? (see page 463)
<source> ::= {CHANnel<n> |
DIGital<d>}
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
