Commands Quick Reference 5
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 115
Table 14 :EXTernal Trigger Commands Summary
Command Query Options and Query Returns
:EXTernal:BWLimit
<bwlimit> (see
page 434)
:EXTernal:BWLimit?
(see page 434)
<bwlimit> ::= {0 | OFF}
:EXTernal:PROBe
<attenuation> (see
page 435)
:EXTernal:PROBe? (see
page 435)
<attenuation> ::= probe
attenuation ratio in NR3 format
:EXTernal:RANGe
<range>[<suffix>]
(see page 436)
:EXTernal:RANGe? (see
page 436)
<range> ::= vertical full-scale
range value in NR3 format
<suffix> ::= {V | mV}
:EXTernal:UNITs
<units> (see page 437)
:EXTernal:UNITs? (see
page 437)
<units> ::= {VOLT | AMPere}
Table 15 :FRANalysis Commands Summary
Command Query Options and Query Returns
n/a :FRANalysis:DATA?
[SWEep | SINGle] (see
page 441)
<binary_block> ::=
comma-separated data with
newlines at the end of each row
:FRANalysis:ENABle
{{0 | OFF} | {1 |
ON}} (see page 442)
:FRANalysis:ENABle?
(see page 442)
{0 | 1}
:FRANalysis:FREQuency
:MODE <setting> (see
page 443)
:FRANalysis:FREQuency
:MODE? (see page 443)
<setting> ::= {SWEep | SINGle}
:FRANalysis:FREQuency
:SINGle
<value>[suffix] (see
page 444)
:FRANalysis:FREQuency
:SINGle? (see
page 444)
<value> ::= {20 | 100 | 1000 |
10000 | 100000 | 1000000 |
10000000 | 2000000}
[suffix] ::= {Hz | kHz| MHz}
:FRANalysis:FREQuency
:STARt
<value>[suffix] (see
page 445)
:FRANalysis:FREQuency
:STARt? (see page 445)
<value> ::= {20 | 100 | 1000 |
10000 | 100000 | 1000000 |
10000000}
[suffix] ::= {Hz | kHz| MHz}
:FRANalysis:FREQuency
:STOP <value>[suffix]
(see page 446)
:FRANalysis:FREQuency
:STOP? (see page 446)
<value> ::= {100 | 1000 | 10000 |
100000 | 1000000 | 10000000 |
20000000}
[suffix] ::= {Hz | kHz| MHz}
:FRANalysis:PPDecade
<value> (see page 447)
:FRANalysis:PPDecade?
(see page 447)
<value> ::= {10 | 20 | 30 | 40 |
50 | 60 | 70 | 80 | 90 | 100}
