Keysight Technologies InfiniiVision 4000 X Series

1434 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
37 :WGEN<w> Commands
:WGEN<w>:MODulation:N
OISe <percent> (see
page 1461)
:WGEN<w>:MODulation:N
OISe? (see page 1461)
<percent> ::= 0 to 100
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:S
TATe {{0 | OFF} | {1
| ON}} (see page 1462)
:WGEN<w>:MODulation:S
TATe? (see page 1462)
{0 | 1}
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:T
YPE <type> (see
page 1463)
:WGEN<w>:MODulation:T
YPE? (see page 1463)
<type> ::= {AM | FM | FSK}
<w> ::= 1 in NR1 format
:WGEN<w>:OUTPut {{0 |
OFF} | {1 | ON}} (see
page 1465)
:WGEN<w>:OUTPut? (see
page 1465)
{0 | 1}
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:OUTPut:LOAD
<impedance> (see
page 1466)
:WGEN<w>:OUTPut:LOAD?
(see page 1466)
<impedance> ::= {ONEMeg | FIFTy}
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:OUTPut:MODE
<mode> (see page 1467)
:WGEN<w>:OUTPut:MODE?
(see page 1467)
<mode> ::= {NORMal | SINGle}
:WGEN<w>:OUTPut:POLar
ity <polarity> (see
page 1468)
:WGEN<w>:OUTPut:POLar
ity? (see page 1468)
<polarity> ::= {NORMal |
INVerted}
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:OUTPut:SINGl
e (see page 1469)
n/a n/a
:WGEN<w>:PERiod
<period> (see
page 1470)
:WGEN<w>:PERiod? (see
page 1470)
<period> ::= period in seconds in
NR3 format
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:RST (see
page 1471)
n/a <w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:TRACk {{0 |
OFF} | {1 | ON}} (see
page 1472)
:WGEN<w>:TRACk? (see
page 1472)
{0 | 1}
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:TRACk:AMPLit
ude {{0 | OFF} | {1 |
ON}} (see page 1473
)
:WGEN<w>:TRACk:AMPLit
ude? (see page 1473)
{0 | 1}
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:TRACk:CSIGna
l (see page 1474)
n/a <w> ::= 1 to (# WaveGen outputs)
in NR1 format
Table 167 :WGEN<w> Commands Summary (continued)
Command Query Options and Query Returns
