:WGEN<w> Commands 37
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 1435
Introduction to
:WGEN<w>
Commands
The :WGEN<w> subsystem provides commands to select the waveform generator
function and parameters.
In the :WGEN<w> commands, the <w> can be 1 or 2, and :WGEN is equivalent to
:WGEN1
Reporting the Setup
Use :WGEN<w>? to query setup information for the WGEN<w> subsystem.
Return Format
The following is a sample response from the :WGEN? query. In this case, the query
was issued following the *RST command.
:WGEN1:FUNC SIN;OUTP 0;FREQ +1.0000E+03;VOLT +500.0E-03;VOLT:OFFS
+0.0E+00;:WGEN1:OUTP:LOAD ONEM
:WGEN<w>:TRACk:FREQue
ncy {{0 | OFF} | {1 |
ON}} (see page 1475)
:WGEN<w>:TRACk:FREQue
ncy? (see page 1475)
{0 | 1}
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:TRACk:PHASe
<phase> (see
page 1476)
:WGEN<w>:TRACk:PHASe?
(see page 1476)
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
<phase> ::= -360 to +360 in NR1
format
:WGEN<w>:VOLTage
<amplitude> (see
page 1477)
:WGEN<w>:VOLTage?
(see page 1477)
<amplitude> ::= amplitude in
volts in NR3 format
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:VOLTage:HIGH
<high> (see page 1478)
:WGEN<w>:VOLTage:HIGH
? (see page 1478)
<high> ::= high-level voltage in
volts, in NR3 format
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:VOLTage:LOW
<low> (see page 1479)
:WGEN<w>:VOLTage:LOW?
(see page 1479)
<low> ::= low-level voltage in
volts, in NR3 format
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
:WGEN<w>:VOLTage:OFFS
et <offset> (see
page 1480)
:WGEN<w>:VOLTage:OFFS
et? (see page 1480)
<offset> ::= offset in volts in
NR3 format
<w> ::= 1 to (# WaveGen outputs)
in NR1 format
Table 167 :WGEN<w> Commands Summary (continued)
Command Query Options and Query Returns
