:WGEN<w> Commands 37
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 1449
Query Syntax :WGEN<w>:FUNCtion?
The :WGEN<w>:FUNCtion? query returns the currently selected signal type.
Return Format
<signal><NL>
<signal> ::= {SIN | SQU | RAMP | PULS | DC | NOIS | SINC | EXPR | EXPF
| CARD | GAUS | ARB}
See Also • "Introduction to :WGEN<w> Commands" on page 1435
• ":WGEN<w>:MODulation:NOISe" on page 1461
GAUSsian Use these commands to set the gaussian pulse
signal parameters:
• ":WGEN<w>:FREQuency" on page 1445
• ":WGEN<w>:PERiod" on page 1470
• ":WGEN<w>:VOLTage" on page 1477
• ":WGEN<w>:VOLTage:OFFSet" on
page 1480
100 mHz to
5MHz
20 mVpp to
7.5 Vpp
±2.50 V
ARBitrary Use these commands to set the arbitrary signal
parameters:
• ":WGEN<w>:FREQuency" on page 1445
• ":WGEN<w>:PERiod" on page 1470
• ":WGEN<w>:VOLTage" on page 1477
• ":WGEN<w>:VOLTage:OFFSet" on
page 1480
• ":WGEN<w>:VOLTage:HIGH" on page 1478
• ":WGEN<w>:VOLTage:LOW" on page 1479
100 mHz to
12 MHz
20 mVpp to
10 Vpp
±5.00 V
1
When the output load is 50 Ω, these values are halved.
2
The minimum amplitude is limited to 40 mVpp if the offset is greater than 500 mV or less than -500 mV. Likewise, the offset
is limited to +/-500 mV if the amplitude is less than 40 mVpp.
Waveform
Type
Characteristics Frequency
Range
Max.
Amplitude
2
(High-Z)
1
Offset
2
(High-Z)
1
