Keysight Technologies InfiniiVision 4000 X Series

152 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
5 Commands Quick Reference
:POD<n>:SIZE <value>
(see page 702)
:POD<n>:SIZE? (see
page 702)
<value> ::= {SMALl | MEDium |
LARGe}
:POD<n>:THReshold
<type>[suffix] (see
page 703)
:POD<n>:THReshold?
(see page 703)
<n> ::= 1-2 in NR1 format
<type> ::= {CMOS | ECL | TTL |
<user defined value>}
<user defined value> ::= value in
NR3 format
[suffix] ::= {V | mV | uV }
Table 23 :POD<n> Commands Summary (continued)
Command Query Options and Query Returns
Table 24 :POWer Commands Summary
Command Query Options and Query Returns
n/a :POWer:CLResponse?
(see page 713)
n/a
:POWer:CLResponse:APP
Ly (see page 714)
n/a n/a
n/a :POWer:CLResponse:DAT
A? [SWEep | SINGle]
(see page 715)
<binary_block> ::=
comma-separated data with
newlines at the end of each row
n/a :POWer:CLResponse:DAT
A:GMARgin? (see
page 716)
<gain_margin> ::= gain margin in
dB in NR3 format.
n/a :POWer:CLResponse:DAT
A:GMARgin:FREQuency?
(see page 717)
<frequency> ::= 0 degrees phase
crossover frequency in Hz in NR3
format
n/a :POWer:CLResponse:DAT
A:PMARgin? (see
page 718)
<phase_margin> ::= phase margin
in degrees in NR3 format.
n/a :POWer:CLResponse:DAT
A:PMARgin:FREQuency?
(see page 719)
<frequency> ::= 0dB gain
crossover frequency in Hz in NR3
format.
:POWer:CLResponse:FRE
Quency:MODE <mode>
(see page 720)
:POWer:CLResponse:FRE
Quency:MODE? (see
page 720)
<mode> ::= {SWEep | SINGle}
:POWer:CLResponse:FRE
Quency:SINGle
<value>[suffix] (see
page 721)
:POWer:CLResponse:FRE
Quency:SINGle? (see
page 721)
<value> ::= {20 | 100 | 1000 |
10000 | 100000 | 1000000 |
10000000 | 2000000}
[suffix] ::= {Hz | kHz| MHz}
