168 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide

5 Commands Quick Reference

:SBUS<n>:CAN:TRIGger:

PATTern:DATA:DLC

<dlc> (see page 899)

:SBUS<n>:CAN:TRIGger:

PATTern:DATA:DLC?

(see page 899)

<dlc> ::= integer between -1

(don't care) and 64, in NR1

format.

:SBUS<n>:CAN:TRIGger:

PATTern:DATA:LENGth

<length> (see

page 900)

:SBUS<n>:CAN:TRIGger:

PATTern:DATA:LENGth?

(see page 900)

<length> ::= integer from 1 to 8

in NR1 format

:SBUS<n>:CAN:TRIGger:

PATTern:DATA:STARt

<start> (see page 901)

:SBUS<n>:CAN:TRIGger:

PATTern:DATA:STARt?

(see page 901)

<start> ::= integer between 0 and

63, in NR1 format.

:SBUS<n>:CAN:TRIGger:

PATTern:ID <string>

(see page 902)

:SBUS<n>:CAN:TRIGger:

PATTern:ID? (see

page 902)

<string> ::= "nn...n" where n ::=

{0 | 1 | X | $}

<string ::= "0xnn...n" where n

::= {0,..,9 | A,..,F | X | $}

:SBUS<n>:CAN:TRIGger:

PATTern:ID:MODE

<value> (see page 903)

:SBUS<n>:CAN:TRIGger:

PATTern:ID:MODE? (see

page 903)

<value> ::= {STANdard | EXTended}

:SBUS<n>:CAN:TRIGger:

SYMBolic:MESSage

<name> (see page 904)

:SBUS<n>:CAN:TRIGger:

SYMBolic:MESSage?

(see page 904)

<name> ::= quoted ASCII string

:SBUS<n>:CAN:TRIGger:

SYMBolic:SIGNal

<name> (see page 905)

:SBUS<n>:CAN:TRIGger:

SYMBolic:SIGNal? (see

page 905)

<name> ::= quoted ASCII string

:SBUS<n>:CAN:TRIGger:

SYMBolic:VALue <data>

(see page 906)

:SBUS<n>:CAN:TRIGger:

SYMBolic:VALue? (see

page 906)

<data> ::= value in NR3 format

Table 29 :SBUS<n>:CAN Commands Summary (continued)

Command Query Options and Query Returns

Table 30 :SBUS<n>:CXPI Commands Summary

Command Query Options and Query Returns

:SBUS<n>:CXPI:BAUDrat

e <baudrate> (see

page 909)

:SBUS<n>:CXPI:BAUDrat

e? (see page 909)

<baudrate> ::= integer from 9600

to 40000 in 100 b/s increments.

:SBUS<n>:CXPI:PARity

{{0 | OFF} | {1 |

ON}} (see page 910)

:SBUS<n>:CXPI:PARity?

(see page 910)

{0 | 1}

:SBUS<n>:CXPI:SOURce

<source> (see

page 911)

:SBUS<n>:CXPI:SOURce?

(see page 911)

<source> ::= {CHANnel<n>}

<n> ::= 1 to (# analog channels)

in NR1 format
